Product Description
CQF Specification
| Model | In/out (diameter) | Hose connection | Maximum output | Standard output | Motor | |||||
| Inlet | Outlet | Inlet | Outlet | Flow | Head | Flow | Head | Power | Voltage | |
| (mm) | (mm) | (mm) | (mm) | (L/min) | (m) | (L/min) | (m) | (KW) | (V) | |
| CQF20-15-105 | 20X15 | 26 | twenty one | 97 | 14.2 | 70 | 10 | 0.37 | 220/380 | |
*Union interface and flanged interface are available upon request. Liquid temperature range: 0-80℃(PP) 0-100℃ (PVDF). Suitable for specific gravity below 1.3 (specify when ordering, should the gravity be higher).
Installing Dimensions
Performance Chart
*Union interface and flanged interface are available upon request. Liquid temperature range: 0-80℃(PP) 0-100℃ (PVDF). Suitable for specific gravity below 1.3 (specify when ordering, should the gravity be higher).
The CQF20-15-105 magnetic drive pump sets a new benchmark in chemical fluid handling, combining corrosion resistance, energy efficiency, and maintenance simplicity for industrial applications. Designed to transfer acids, alkalis, and other aggressive media, this pump eliminates leakage risks through its innovative sealless construction.
Optimized Performance & Durability
Featuring a reinforced fiberglass body and integrated injection-molded impeller-magnetic rotor assembly, the CQF20-15-105 minimizes hydraulic losses while reducing internal component volume. This energy-efficient design extends service life and lowers operational costs. All wetted parts—including the casing, impeller, and containment shell—utilize reinforced polypropylene (RPP), while the shaft and bearings incorporate specialty corrosion-resistant alloys.
Uncompromised Safety
The pump’s sealless magnetic coupling ensures zero leakage, protecting operators and environments from hazardous fluid exposure. Its advanced material engineering allows safe transfer of concentrated acids (e.g., sulfuric, hydrochloric), caustic solutions, and solvents up to 90°C.
Engineered for Efficiency
Modular design: Enables rapid disassembly for inspection or part replacement
Plug-in maintenance: Key components are field-serviceable without specialized tools
Reduced downtime: Axial bearing monitoring ports simplify preventive maintenance
Ideal for chemical processing, electroplating, and wastewater treatment, the CQF20-15-105 delivers flow rates up to 12m³/h (53 GPM) with heads reaching 14m (46 ft). Its compact footprint and ATEX-compliant options make it adaptable to space-constrained or explosive atmospheres.
By merging robust materials, sealless technology, and modular serviceability, this pump redefines reliability in critical fluid transfer operations.
