Integrated Installation Drawing and Standard BOM Documents Standardize Global Engineering Matching & On-site Layout Construction

When industrial pump products are applied in overall turnkey environmental projects, electroplating production line renovation and chemical workshop fluid system construction, engineering designers need accurate outline sizes, interface dimensions and component lists for pipeline layout design, support frame production and bidding document compilation. Non-standardized scattered technical materials will prolong project design cycles and easily cause installation size mismatches on site.

Yida sorts out unified standardized technical files for every model within the magnetic pump, self-priming pump and vertical pump product matrix. Each product is attached with dimensional outline drawings, pipeline connection size tables, complete spare parts BOM and installation space reservation parameters. All technical documents are compiled in universal international drawing standards, which can be directly embedded into the overall engineering design scheme by global engineering suppliers.

Complete standardized technical documentation improves the docking efficiency between Yida pumps and global system integrators, reduces design errors and on-site installation rework problems, and enhances product matching efficiency in international engineering bidding markets.
